AWS 65 Casement window

FEATURES

• Excellent thermal insulation due to hollow chamber centre gasket and wide insulation zone
• Concealed drainage, at the lowest profile point
• Use of crimped and nailed corner cleats as well as screw-type connection technology as an additional, new connection option for optimised noise levels and tolerance equalisation
• Burglar resistance up to WK3 (RC 3) in accordance with DIN V ENV 1627
• Solution for easy-access patio and balcony doors in turn/tilt and double-vent design
• New, outward-opening window series with centre gasket also available as a double-vent window; also with burglar resistance in accordance with PAS 24

Parameter	Testing Value	Testing Standard
Water tightness	9A (600 Pa)	DIN EN 12208
Wind load resistance	Class C5/B5 (2000 Pa)	DIN EN 12210
Air permeability	Class 4 (600 Pa)	DIN EN 12207
Thermal Insulation	Uf=1.9-2.5 W/m2K	DIN EN ISO 10077-2

Handle Options for Inward Opening	Standards window handle	Windows handle, short	Security window handle, lockable	Security window handle, with push button lock	Push-in window handle
Colors	C0, RAAL 9005, RAAL 9010, RAAL 9016, INOX, INOX-Look	C0, RAAL 9005, RAAL 9010, RAAL 9016, INOX, INOX-Look	C0, RAAL 9005, RAAL 9010, RAAL 9016, INOX, INOX-Look	C0, RAAL 9005, RAAL 9010, RAAL 9016, INOX, INOX-Look	C0, RAAL 9005, RAAL 9010, RAAL 9016
Handle Options for Inward Opening	Push-in window handle	Push-in window handle	Push-in window handle	Push-in window handle	Push-in window handle
Colors	C0, RAAL 9005, RAAL 9010, RAAL 9016	C0, INOX	C0, INOX	C0, INOX	C0, INOX
